XG555-S-DEV
SSI to DeviceNet Gateway
Overview
Transitioning to DeviceNet? Use your existing SSI sensors with your new controller.
The XG555-S-DEV is a gateway device that interrogates SSI protocol sensors and makes that information available over a DeviceNet fieldbus network.
Position information from up to two sensors can be collected.
Description
The XG555-R-DEV functions as a DeviceNet slave with configurable address and baud rate. Up to two sensors are continuously interrogated for position. The collected position information is scaled, then output to the DeviceNet master.
Features
- Supports up to two SSI sensors
- Configurable position scaling
Specifications
| Parameter | Units | Min | Typ | Max | Notes |
|---|---|---|---|---|---|
| Bus Interface | — | — | — | — | DeviceNet release 2.0 |
| Supply Power | DC Volts | 22 | 24 | 26 | |
| Supply Power | mA | — | — | 500 | |
| Supported Sensors | — | — | — | 4 | |
| Bus Interface | — | — | — | — | CAN ISO DIS 11898 |
Downloads
-
User Manual
Download Adobe PDF
